Diagnostic Socket Location Manual
SKU
LT476
Sign in or request an account to see prices.
Handy time saving manual which shows the location of the EOBD 16 pin diagnostic socket.
- Shown in photographs of the cockpit area and line drawings
- Terminal description and location for each of the 16 pins in relation to the socket
- Lists over 500 common model types
Handy time saving manual which shows the location of the EOBD 16 pin diagnostic socket using photographs of the cockpit area and line drawings.
Features a terminal description and location for each of the 16 pins in relation to the socket.
Lists over 500 common model types.
| Brandname | SKS |
|---|
